120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES

Product Categories
FUZHOU THINMAX SOLAR CO., LTD
Contact Now

120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES

Place of Origin : Shenzhen

Brand Name : Growatt

Model Number : SPF 5000 ES

Packaging Details : One piece per carton.

Supply Ability : 100 Piece/Pieces per Week

MOQ : 10 pieces

Price : $590.00/pieces 10-99 pieces

Input Voltage : 230v

Output Voltage : 230VAC ± 5%

Output Current : 18.4A

Output Frequency : 50Hz/60Hz

Output Type : Three Phase

Size : 330 x 485 x 135mm

Type : DC/AC Inverters

Inverter Efficiency : 98%

Certificate : CE Rohs

Warranty : 5 years

Weight : 15kg

Port : Ningbo, Shanghai, Shenzhen

Contact Now

120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES​
Product Description
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
Datasheet SPF 3500 ES SPF 5000 ES
Battery Voltage 48VDC
Battery Type Lithium/Lead-acid
INVERTER OUTPUT
Rated Power 3500VA/ 3500W 5000VA/ 5000W
Parallel Capability Yes, 6 units maximum
AC Voltage Regulation
(Battery Mode)		 230VAC ± 5% @ 50/60Hz
Surge Power 7000VA 10000VA
Efficiency (Peak) 93%
Waveform Pure sine wave
Transfer Time 10ms typical, 20ms Max
SOLAR CHARGER
Maximum PV Array Power 4500W 6000W
MPPT Range @ Operating Voltage 120VDC ~ 430VDC
Number of Independent MPP Trackers/ Strings Per MPP Tracker 1/1
Maximum PV Array Open Circuit Voltage 450VDC
Maximum Solar Charge Current 80A 100A
AC CHARGER
Charge Current 60A 80A
AC Input Voltage 230 VAC
Selectable Voltage Range 170-280 VAC (For Personal Computers): 90-280 VAC (For Home Appliances)
Frequency Range
inmax Sole		 50Hz/60Hz (Auto sensing)
PHYSICAL
Protection Degree IP20
Dimension (W/H/D) 330/485/135mm 330/485/135mm
Net Weight 11.5kgs 12kgs
OPERATING ENVIRONMENT
Humidity 5% to 95% Relative Humidity(Non-condensing)
Altitude <2000m
Operating Temperature 0°C - 55°C
Storage Temperature -15°C -60°C

120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
Company Profile

120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES

Fuzhou Thinmax is a solar company located at the city Fuzhou which is the capital of Fujian province. We have about 50 office colleagues and 100 factory colleagues. With the professional colleagues and over 10 years experience of dealing with solar system, we are able to provide 100% satisfying service for customers. Not only for the ready products but also the customized products. In order to make the ship more fluently. We have cooperated with more than 20 shipping companies. After customers place the order. We will always choose the cheapest and reliable one to arrange the shipment. When customers have received the items. We have professional technician ready for customers if they have any problems.
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
Why Choose Us
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
Product packaging
120v 240v Growatt Off Grid Solar Inverter 5KW Inverter Split Phase SPF 5000 ES
FAQ
Q1: What is the delivery time?
A1: It's according to the model. We will ship the items within 3 days if the items in stock.

Q2: What ways of payment do you accept.
A2: We can accept LC, Paypal, Credit card, etc.

Q3: Will you provide shipping sevice?
A3: Yes. We will choose the best shipping way and shipping company for the customers according to the demands.

Q4: What if we have problems after sale?
A4: Don't worry. We have professional technicians ready for our customers who can take care of the problems.

Q5: What is the minimum quantity?
A5: We can send a sample to you. If you are satisfied with our products and service. Please place larger quantity to us.

Q6: Are the inverters original?
A6: Yes. Of course. If it's not. We will return all money back to you.
